AMPLIFIER:
|
|
 |
 #
Channels |
7.2
|
|
|
|
POWER (8 Ω 20-20kHZ
0.08%) / CH |
135
|
|
|
|
POWER (8 Ω 20-20kHZ
0.05%) / CH |
-
|
|
|
|
Amplifier Frequency
Response (WRAT)
|
5Hz - 100kHz
|
|
|
|
THX
Certified |
Select2 Plus
|
|
|
|
Continuous
6 Ω Rated |
|
|
|
|
Certified 4 Ω
Performance |
|
|
|
|
Discrete Output Stages
for All Channels
|
|
|
|
|
Absolute
Ground Plate
|
|
|
|
|
PUSH-PULL Amplifier
Design |
|
|
|
|
3-Stage Inverted
Darlington Circuitry
|
|
|
|
|
Independent
Block Construction
(Amp/Preprocessor)
|
-
|
|
|
|
Shielded Toroidal
Transformer |
-
|
|
|
|
Independent
Power Supply
|
2
|
|
|
|
Fine Linear Optimum Gain
Volume |
|
|
|
|
Bi-amp
Capability For Front
|
|
|
|
|
Bridging (BTL)
Capability for Front
|
-
|
|
|
PROCESSING:
|
|
|
|
|
Dolby TrueHD, Dolby
Digital Plus Decoding
|
|
|
|
DTS-HD Master Audio,
DTS-HD Express Decoding
|
|
|
|
|
Dolby Pro Logic IIz
(Front High Channels)
|
|
|
|
|
Dolby Volume
|
-
|
|
|
|
THX Processing Modes &
Loudness Plus
|
|
|
|
|
Neural Surround
|
-
|
|
|
|
Audyssey Room Correction
& Calibration
|
MultEQ
|
|
|
|
Audyssey MultEQ Pro /
Installer Ready
|
-
|
|
|
|
Audyssey DSX (Front High
/ Wide Channels)
|
|
|
|
|
Audyssey Dynamic EQ &
Dynamic Volume
|
|
|
|
GAME Surround Modes
(Rock, Action, Sports,
Role Play) |
|
|
|
Music Optimizer to
Enhance
Compressed Audio Files
|
|
|
|
|
DSD Processing / Direct
Mode |
/ -
|
|
|
|
192K / 24-Bit Audio DAC
|
Burr-Brown (PCM1690)
|
|
|
|
192K / 32-Bit Audio DAC
|
-
|
|
|
|
Vector Linear Shaping
Circuitry (VLSC)
|
-
|
|
|
|
32-Bit DSP Chip for
Advanced Processing
|
TI Aureas (x2)
|
|
|
|
Ultra-Low-Jitter
Circuitry to Improve
Audio |
Jitter Clean
|
|
|
|
Adjustable Crossover by
Channel Pair
|
40/45/50/55/60/70/80/90
100/110/120/130/150/200
|
|
|
|
Accurate Speaker
Distance Setting
|
0.2-foot
|
|
|
|
A/V Sync Delay (by
Source) |
250ms
|
|
|
|
Multi-Band Speaker EQ
|
15
|
|
|
|
ISF Certified
Calibration Controls (ISFccc)
|
|
|
|
CONNECTIVITY:
|
|
|
|
|
HDMI v1.4a (3D Support,
Audio Return Channel)
|
|
|
|
|
Deep Color, x.v.Color,
CEC |
|
|
|
|
HDMI Inputs / Output(s)
|
7 + 1 / 2
|
|
|
Simultaneous or
Independently Active
HDMI Outputs (Main /
Sub) |
|
|
|
|
Front Panel HDMI Input
|
|
|
|
HDMI Upscaling &
Upconversion 1080P
4K Upscaling (3840 x
2160)
|
(HQV Vida)
Marvell Kyoto G2H
|
|
|
|
D-Sub (15-pin) VGA Input
|
|
|
|
|
Component Video Inputs /
Output(s) |
3 / 1
|
|
|
|
Component Video
Upscaling & Upconversion
|
(HQV Vida)
|
|
|
|
Composite Video Inputs /
Output(s) |
5 / 1
|
|
|
|
S-Video Inputs /
Output(s) |
4 / 1
|
|
|
|
Digital Audio Inputs
(OPT / COAX)
|
3 / 2
|
|
|
|
Analog Audio Inputs /
Output(s) |
8 / 2
|
|
|
|
Phono Input |
|
|
|
|
Front Panel A/V Input
|
L / R / V / Optical
|
|
|
|
Multi-Channel Input
|
7.1
|
|
|
|
Analog Pre-outs
|
7.2
|
|
|
|
iPod / iPhone Ready
|
(UP-A1 & USB)
|
|
|
|
HD Radio Ready
|
(UP-HT1)
|
|
|
|
SIRIUS Radio Ready
|
|
|
|
Network Audio Steaming
(Windows 7, DLNA v1.5
Certified) |
|
|
|
|
Pandora, Rhapsody,
vTuner, SIRIUS iRadio
|
|
|
|
|
Napster, Slacker,
MediaFly |
|
|
|
|
USB Input for Streaming
Audio |
|
|
|
|
Firmware Updates via
Network / USB
|
/
|
|
|
MULTIZONE:
|
|
|
|
|
Powered Zone 2/ Zone 3 /
Zone 4 |
/ - / -
|
|
|
|
Fixed or Variable Zone 2
/ Zone 3 Line Out
|
/
|
|
|
|
Zone 2 / Zone 3
Subwoofer Output
|
-
|
|
|
|
Zone 2 Video Output
|
(Composite/Component)
|
|
|
INTEGRATION ACCESS:
|
|
|
|
|
Bi-directional RS-232
Control Port
|
|
|
|
|
Bi-directional Ethernet
Control Port
|
|
|
|
|
Rear Panel IR Input /
Output |
2 / 1
|
|
|
|
RIHD
(Remote Interactive over
HDMI) |
|
|
|
|
RI
System Control
|
|
|
|
|
12V
Trigger (w/adjustable
delay) |
Assignable (x3)
|
|
|
MISC:
|
|
|
|
|
Pre-programmed /
Learning Remote
|
/
|
|
|
|
GUI for Remote Control
Programming |
|
|
|
|
GUI
for Setup Menu
|
|
|
|
|
"Home" GUI |
|
|
|
|
Bi-directional Remote
Control Setup
|
|
|
|
Activity Remote
(MY MOVIE, MY TV, MY
MUSIC, ALL OFF)
|
|
|
|
|
Input
Name Edit |
|
|
|
|
HDMI Standby "Thru" Mode
|
|
|
|
|
Setup Store & Recall
Function |
|
|
|
|
Permanent
Memory Storage
|
|
|
|
|
Solid Aluminum Front
Panel |
|
|
|
|
Aluminum Volume Knob
|
(Sand Finished)
|
|
|
|
Detachable
AC Cord |
|
|
|
|
Rack
Mount Kit Available
|
IRK-180-4
|
|
|
|
Warranty
|
5 YEARS
|
